Features
Mainframe
Pierced main beam construction with one piece interlocking crossmembers; W12″ x 16 lbs. per ft., grade 50; Hi-tensile.
Crossmembers
6″ I-beam x 3.7 lbs. per ft.; grade 50 Hi-tensile on 18″ centers.
Siderails
C8″ x 11.5 lbs. per ft.; grade 50 Hi-tensile
Suspension
Hutch 9700 multi-point spring with radius rod axle tracking adjustment, 44,000 lb. capacity
Axles
(2) “Dexter” 12,000 lb.
Brakes
Air 12-1/4″ x 5″ – ABS
Wheels
8 hole steel disc
Tires
(6) 235/80R16, (E) Capacity: 3,000 lbs.
Landing Gear
12,000 lb.
Finish
Black acrylic enamel; rust prohibitive undercoating
Floor
2″ nominal oak secured to crossmembers with 5/16″ torque screws.
Lights
12 volt DOT & ICC approved; all lights are LED type and flush mounted in rubber grommets; wiring is run in flexible neoprene jacket and modular in design; 7-way plug.
Tiedowns
(8) heavy duty D-rings, 4 per side.
Loading Ramps
58″ x 21.5″ traction with spring assist.
Options
- Yellow, white, gray or red acrylic enamel.
| Model | 24DTA |
| Dimensions | 29' long 24' (19' flat deck + 5' beavertail) deck length 8' deck width 34" deck height (unloaded) |
| Approximate Weight | 6250 lbs. |
| GVWR | 24000 lb. capacity tag-along trailer with air brakes beavertail & ramps (at 55 MPH GVWR 30250 lbs.) |
